Environmental temperature:-35 ℃ ~55 ℃
The relative temperature:The average <95%, average <90%
Voltage level:35~500kV
The working power supply:AC220V (or DC110V, 220V)
Forced locking contact capacity:AC220V / 2A
Device power consumption:4W
Rated frequency:50Hz
Display signal:1, light: digital display 2, audio voice alarm
Mounting distance and start distance sensor:
Rated voltage (kV) 35140220330500
Mounting distance (CM) 35140250360500
The distance (CM) 1502504006001200
Reliability:Non contact type sensor is in the range of distance line safety, the installation of on-line detection of line source are charged. But with obvious directivity, high sensitivity, high safety and reliability
Safety:The sensor is not in direct contact with the charged body, therefore the installation is simple and convenient, safe and reliable, no partial discharge test and maintenance, low maintenance cost, long service life.
Full function:The device has A, B, C three-phase digital display, audio alarm checking and start forced locking loop function. Truly and effectively prevent the occurrence of accidents caused by false operation;
Applicability:Forms can be widely applied in various places sub indoor, outdoor, GIS combination electric appliance and switchgear etc., is an ideal safety device for preventing electrical misoperation 35-500KV indoor, outdoor electrical equipment or network, can be five proof device interface. With man-machine conversation, GPRS data transmission function.
Interactive:Construction personnel can be equipped with induction device, a vibration and sound and light alarm, for the error near the charged device, in the establishment of a warning.
